产品名称：华新科0805/2012_贴片电容_片容_贴片电容器

所属类别：华新科0805/2012_贴片电容_片容_贴片电容器

产品简介：华新科贴片电容0805/2012,华新科片容0805/2012,华新科贴片电容器0805/2012电话：0769-89917065

详细介绍

华新科0805/2012

华新科0805/2012贴片电容参数

品牌	WALSIN/华新科	型号	0805/2012	介质材料	陶瓷(瓷介)
应用范围	低压	外形	方块状	功率特性	小功率
频率特性	低频	调节方式	固定	引线类型	无引线
允许偏差	±5（%）	耐压值	50（V）	等效串联电阻(ESR)	0（mΩ）
标称容量	100pF~220uF（uF）	损耗	0	额定电压	6.3（V）
绝缘电阻	0（mΩ）	温度系数	0

华新科0805/2012贴片电容

华新科0805/2012贴片电容器

0805/2012华新科

0805/2012华新科片容

华新科0805/2012 贴片电容片容贴片电容器清洗

1) If an unsuitable cleaning fluid is used, flux residue or some foreign article may stick to chip capacitor
surface causing deteriorated performance, especially insulation resistance.
2) If the cleaning condition is not suitable, it may damage the chip capacitor.
2-1) Insufficient washing
(1) Lead wire and terminal electrodes may corrode due to Halogen in the flux.
(2) Halogen in the flux may adhere on the surface of capacitor, and lower the insulation resistance.
(3) Water soluble flux has higher tendency to have the above mentioned problems (1) and (2).
2-2) Excessive washing
When ultrasonic cleaning is used, excessively high ultrasonic energy output can affect the
connection between the ceramic chip capacitor’s body and the terminal electrode. To avoid this,
use the following recommended condition.
Power : 20W/l max.
Frequency : 40kHz max.
Washing time : 5 minutes max.
2-3) If the cleaning fluid is contaminated, the density of Halogen increases, and it may bring the same
