国巨高压1210/3225贴片电容基础参数:
品牌 | YAGEO/国巨 | 型号 | 1210/3225 | 介质材料 | 陶瓷(瓷介) |
应用范围 | 高压 | 外形 | 方块状 | 功率特性 | 大功率 |
频率特性 | 高频 | 调节方式 | 可变 | 引线类型 | 无引线 |
允许偏差 | ±10(%) | 耐压值 | 500(V) | 等效串联电阻(ESR) | 0(mΩ) |
标称容量 | 10pF~10nF(uF) | 损耗 | 0 | 额定电压 | 50(V) |
绝缘电阻 | 0(mΩ) | 温度系数 | 0 |
国巨高压1210/3225 贴片电容 片容 贴片电容器订购相关
ORDERING INFORMATION - GLOBAL PART NUMBER
All part numbers are identified by the series, size, tolerance, TC material,
packing style, voltage, process code, termination and capacitance value.
GLOBAL PART NUMBER
AC XXXX X X XXX X B X XXX
(1) (2) (3) (4) (5) (6) (7)
(1) SIZE – INCH BASED (METRIC)
0402 (1005) / 0603 (1608) / 0805 (2012) / 1206 (3216)/ 1210 (3225) / 0508 (1220) /
0612 (1632)
(2) TOLERANCE
B = ±0.1 pF
C = ±0.25 pF
D = ±0.5 pF
G = ±2%
J = ±5%
K = ±10%
M = ±20%
(3) PACKING STYLE
R = Paper/PE taping reel; Reel 7 inch
K = Blister taping reel; Reel 7 inch
P = Paper/PE taping reel; Reel 13 inch
F = Blister taping reel; Reel 13 inch
(4) TC MATERIAL
NPO
X7R
( 5 ) RATED VOLTAGE
5 = 6.3 V
6 = 10 V
7 = 16 V
8 = 25 V
9 = 50 V
0 = 100 V
A = 200 V
Y = 250 V
B = 500 V
Z = 630 V
(6) PROCESS
N = NP0
B = Class 2 MLCC
(7) CAPACITANCE VALUE
2 significant digits+number of zeros
The 3rd digit signifies the multiplying factor, and letter R is decimal point
