高压三星1808/4520贴片电容基本参数:
品牌 | Samsung/三星 | 型号 | 1808/4520 | 介质材料 | 陶瓷(瓷介) |
应用范围 | 高压 | 外形 | 方块状 | 功率特性 | 小功率 |
频率特性 | 低频 | 调节方式 | 固定 | 引线类型 | 无引线 |
允许偏差 | ±2(%) | 耐压值 | 3000(V) | 等效串联电阻(ESR) | 0(mΩ) |
标称容量 | 1nF~3.3nF(uF) | 损耗 | 0 | 额定电压 | 1000(V) |
绝缘电阻 | 0(mΩ) | 温度系数 | 0 |
| Product Lineup (Medium-High Voltage Capacitors-COG)
Part Number | Size Lx W (mm) | Capacitance | Rated Voltage (Vdc) | Capacitance Tolerance | Thickness Max. (mm) | |
26 | CL21C121JDCNNN [ | 2.00x1.25 | 120pF | 200 | ±5% | 0.95 |
27 | CL21C151JCANNN [ | 150pF | 100 | ±5% | 0.75 | |
28 | CL21C151JHFNNN 口 | 150F | 630 | ±5% | 1.35 | |
29 | CL21C221JCANNN : | 220pF | 100 | ±5% | 0.75 | |
30 | CL21C221JDCNNN □ | 220pF | 200 | ±5% | 0.95 | |
31 | CL21C331JCANNN | 330pF | 100 | ±5% | 0.75 | |
32 | CL21C471JCCNNN | 470pF | 100 | ±5% | 0.95 | |
33 | CL21C561JCCNNN [ | 560pF | 100 | ±5% | 0.95 | |
34 | CL21C561JHFNNN 口 | 560pF | 630 | ±5% | 1.35 | |
35 | CL21C681JCCNNN | 680pF | 100 | ±5% | 0.95 | |
36 | CL21C102JCFNNN [ | InF | 100 | ±5% | 1.35 | |
37 | CL21C102JDFNNN [ | InF | 200 | ±5% | 1.35 | |
38 | CL21C272JDFNNN : | 2.7F | 200 | ±5% | 1.35 | |
39 | CL21 C272 JEFNNN | 2.7F | 250 | ±5% | 1.35 | |
40 | CL21C472JCFNNN 口 | 4.7F | 100 | ±5% | 1.35 | |
1 | ⑴1C150JGFNNN [ | 3.20x1.60 | 15pF | 500 | ±5% | 1.40 |
2 | CL31C180JGFNNN c | 18pF | 500 | ±5% | 1.40 | |
3 | ⑴1C220JGFNNN [ | 22 pF | 500 | ±5% | 1.40 | |
4 | CL31C220JJHNNN [ | 22 pF | 2000 | ±5% | 1.80 | |
5 | CL31C270JGFNNN [ | 27pF | 500 | ±5% | 1.40 | |
6 | ⑴1C330JGFNNN [ | 33pF | 500 | ±5% | 1.40 | |
7 | CL31C390JGFNNN [ | 39pF | 500 | ±5% | 1.40 | |
8 | ⑴1C470JGFNNN [ | 47pF | 500 | ±5% | 1.40 | |
9 | CL31C470JHFNNN | 47pF | 630 | ±5% | 1.40 | |
10 | CL31C470JIFNNN [ | 47, | 1000 | ±5% | 1.40 | |
11 | CL31C470JJHNNN [ | 47pF | 2000 | ±5% | 1.80 | |
12 | ⑴1C560JGFNNN [ | 56pF | 500 | ±5% | 1.40 | |
13 | CL31C680JCCNNN | 68pF | 100 | ±5% | 1.00 | |
14 | ⑴1C680JGFNNN [ | 68pF | 500 | ±5% | 1.40 | |
15 | CL31C680JHFNNN | 68pF | 630 | ±5% | 1.40 | |
16 | CL31C680JIFNNN | 68pF | 1000 | ±5% | 1.40 | |
17 | CL31C820JGFNCN | 82 pF | 500 | ±5% | 1.40 | |
18 | CL31C101JGFNNN | 100pF | 500 | ±5% | 1.40 | |
19 | CL31C101JHFNNN | 100pF | 630 | ±5% | 1.40 | |
20 | CL31C101JIFNNN | 100pF | 1000 | ±5% | 1.40 | |
21 | CL31C101JJHNNN [ | 100pF | 2000 | ±5% | 1.80 | |
22 | CL31C121JGFNNN | 120pF | 500 | ±5% | 1.40 | |
23 | CL31C151JGFNNN □ | 150F | 500 | ±5% | 1.40 | |
24 | CL31C181JGFNNN | 180F | 500 | ±5% | 1.40 | |
25 | CL31C221JGFNNN | 220pF | 500 | ±5% | 1.40 | |
26 | CL31C271JGFNNN | 270pF | 500 | ±5% | 1.40 | |
27 | CL31C271JCCNNN | 270pF | 100 | ±5% | 1.00 | |
28 | CL31C331JGFNNN | 330pF | 500 | ±5% | 1.40 | |
29 | CL31C331JIHNNN [ | 330pF | 1000 | ±5% | 1.80 | |
30 | CL31C391JCCNNN | 390pF | 100 | ±5% | 1.00 | |
31 | CL31C471JGFNNN | 470pF | 500 | ±5% | 1.40 | |
32 | CL31C471JHFNNN | 470pF | 630 | ±5% | 1.40 | |
33 | CL31C471JIFNNN | 470pF | 1000 | ±5% | 1.40 | |
34 | CL31C561JCCNNN | 560pF | 100 | ±5% | 1.00 | |
35 | CL31C561JGFNNN | 560pF | 500 | ±5% | 1.40 | |
36 | CL31C681JGFNNN | 680pF | 500 | ±5% | 1.80 | |
37 | CL31C821JHHNNN | 820 pF | 630 | 5% | 1.80 |
