三星高压1210/3225贴片电容参数:
品牌 | Samsung/三星 | 型号 | 1210/3225 | 介质材料 | 陶瓷(瓷介) |
应用范围 | 高压 | 外形 | 方块状 | 功率特性 | 小功率 |
频率特性 | 低频 | 调节方式 | 固定 | 引线类型 | 无引线 |
允许偏差 | ±2(%) | 耐压值 | 3000(V) | 等效串联电阻(ESR) | 0(mΩ) |
标称容量 | 330pF~56nF(uF) | 损耗 | 0 | 额定电压 | 100(V) |
绝缘电阻 | 0(mΩ) | 温度系数 | 0 |
| Product Lineup (Medium-High Voltage Capacitors-COG)
Part Number | Size Lx W (mm) | Capacitance | Rated Voltage (Vdc) | Capacitance Tolerance | Thickness Max. (mm) | |
1 | CL10C100JC8NNN □ | 1.60x0.80 | 10pF | 100 | ±50% | 0.90 |
2 | CL10C150JC8NNN □ | 15pF | 100 | ±5% | 0.90 | |
3 | CL10C330JC8NNN □ | 33pF | 100 | ±5% | 0.90 | |
4 | CL10C390JC8NNN □ | 39pF | 100 | ±5% | 0.90 | |
5 | CL10C470JC8NNN 口 | 47pF | 100 | ±5% | 0.90 | |
6 | CL10C560JC8NNN □ | 56pF | 100 | ±5% | 0.90 | |
7 | CL10C101JC8NNN | 100pF | 100 | ±5% | 0.90 | |
8 | CL10C121JC8NNN □ | 120F | 100 | ±5% | 0.90 | |
9 | CL10C151JC8NNN | 150F | 100 | ±5% | 0.90 | |
10 | CL10C331JC8NNN | 330pF | 100 | ±5% | 0.90 | |
11 | CL10C331JD8NNN | 330pF | 200 | ±5% | 0.90 | |
12 | CL10C331JE8NNN | 330pF | 250 | ±5% | 0.90 | |
13 | CL10C391JD8NNN | 390pF | 200 | ±5% | 0.90 | |
14 | CL10C391JE8NNN | 390pF | 250 | ±5% | 0.90 | |
15 | CL10C471JC8NNN | 470pF | 100 | ±5% | 0.90 | |
16 | CL10C471JD8NNN | 470pF | 200 | ±5% | 0.90 | |
17 | CL10C471JE8NNN | 470pF | 250 | ±5% | 0.90 | |
18 | CL10C561JD8NNN | 560pF | 200 | ±5% | 0.90 | |
19 | CL10C561JE8NNN | 560pF | 250 | ±5% | 0.90 | |
20 | CL10C681JC8NNN | 680pF | 100 | ±5% | 0.90 | |
21 | CL10C681JD8NNN | 680pF | 200 | ±5% | 0.90 | |
22 | CL10C681JE8NNN | 680pF | 250 | ±5% | 0.90 | |
23 | CL10C821JC8NNN □ | 820 pF | 100 | ±5% | 0.90 | |
24 | CL10C102JC8NNN □ | InF | 100 | ±50% | 0.90 | |
25 | CL10C122JC8NNN □ | 1.2 nF | 100 | ±5% | 0.90 | |
1 | CL21C100JCANNN □ | 2.00x1.25 | 10pF | 100 | ±5% | 0.75 |
2 | CL21C120JCANNN 口 | 12pF | 100 | ±5% | 0.75 | |
3 | CL21C150JCANNN 口 | 15pF | 100 | ±5% | 0.75 | |
4 | CL21C150JDCNNN □ | 15pF | 200 | ±5% | 0.95 | |
5 | CL21C180JCANNN □ | 18pF | 100 | ±5% | 0.75 | |
6 | CL21C180JDCNNN □ | 18pF | 200 | ±5% | 0.95 | |
7 | CL21C220JCANNN □ | 22 pF | 100 | ±5% | 0.75 | |
8 | CL21C270JCANNN □ | 27pF | 100 | ±5% | 0.75 | |
9 | CL21C270JHFNNN □ | 27pF | 630 | ±5% | 1.35 | |
10 | CL21C330JCANNN □ | 33pF | 100 | ±5% | 0.75 | |
11 | CL21C330JDCNNN □ | 33pF | 200 | ±5% | 0.95 | |
12 | CL21C330JHFNNN 口 | 33pF | 630 | ±5% | 1.35 | |
13 | CL21C390JDCNNN □ | 39pF | 200 | ±5% | 0.95 | |
14 | CL21C470JCANNN | 47pF | 100 | ±5% | 0.75 | |
15 | CL21C470JDCNNN □ | 47pF | 200 | ±5% | 0.95 | |
16 | CL21C470JHFNNN □ | 47pF | 630 | ±5% | 1.35 | |
17 | CL21C560JCCNNN □ | 56pF | 100 | ±5% | 0.95 | |
18 | CL21C560JDCNNN □ | 56pF | 200 | ±5% | 0.95 | |
19 | CL21C680JCANNN | 68pF | 100 | ±5% | 0.75 | |
20 | CL21C680JDCNNN □ | 68pF | 200 | ±5% | 0.95 | |
21 | CL21C680JHFNNN 口 | 68pF | 630 | ±5% | 1.35 | |
22 | CL21C820JCCNNN □ | 82 pF | 100 | ±5% | 0.95 | |
23 | CL21C101JCANNN | 100pF | 100 | ±5% | 0.75 | |
24 | CL21C101JDCNNN 口 | 100pF | 200 | ±5% | 0.95 | |
25 | CL21C101JECNNN | 100pF | 250 | ±5% | 0.95 |
※口mark means packaging code. If you want to learn the code or quantity in detail, please see p80.
